ABS-Enclosures MBT / Clear Cover

ABS-Enclosures MBT / Clear Cover

Material cover: Polycarbonate

Material base: ABS

Material sealing: Polyurethane

Material screws: Stainless Steel V2 A

Silicone-free: Yes

Halogen-free: Yes

UV-resistant: No

MBT Enclosures offer excellent properties for the installation of electronic and electrical components as well as complete control systems for indoor applications.

The MBT Enclosures can be mechanically processed in a number of ways providing almost no limits to customised surface design, including silk screen printing and membrane keyboards.

The enclosures are available with a grey or transparent cover (K).


0402100100	MBT 050504K	52 mm	50 mm	35 mm	Request
0402100200	MBT 060504K	65 mm	50 mm	35 mm	Request
0402100400	MBT 060505K	65 mm	50 mm	45 mm	Request
0402100500	MBT 060545K	65 mm	50 mm	45 mm	Request
0402100600	MBT 060555K	65 mm	50 mm	55 mm	Request
0402100800	MBT 090603K	98 mm	64 mm	37 mm	Request
0402100900	MBT 080805K	82 mm	80 mm	55 mm	Request
0402101200	MBT 080807K	82 mm	80 mm	65 mm	Request
0402101300	MBT 080809K	82 mm	80 mm	85 mm	Request
0402101400	MBT 080810K	82 mm	80 mm	95 mm	Request
0402101500	MBT 128035K	120 mm	80 mm	36 mm	Request
0402101600	MBT 128040K	120 mm	80 mm	41 mm	Request
0402101700	MBT 128045K	120 mm	80 mm	47 mm	Request
0402101900	MBT 128050K	120 mm	80 mm	50 mm	Request
0402102100	MBT 128055K	120 mm	80 mm	55 mm	Request
0402102300	MBT 128060K	120 mm	80 mm	60 mm	Request
0402102330	MBT 128060K	120 mm	80 mm	60 mm	Request
0402102340	MBT 128065K	120 mm	80 mm	65 mm	Request
0402102500	MBT 128070K	120 mm	80 mm	70 mm	Request
0402102550	MBT 128070K	120 mm	80 mm	70 mm	Request
0402102700	MBT 128080K	120 mm	80 mm	80 mm	Request
0402102750	MBT 128080K	120 mm	80 mm	80 mm	Request
0402102900	MBT 128085K	120 mm	80 mm	85 mm	Request
0402103100	MBT 128090K	120 mm	80 mm	90 mm	Request
0402103300	MBT 128010K	120 mm	80 mm	100 mm	Request
0402103601	MBT 168035K	160 mm	80 mm	37 mm	Request
0402103500	MBT 168055K	160 mm	80 mm	55 mm	Request
0402103700	MBT 168060K	160 mm	80 mm	60 mm	Request
0402103800	MBT 168085K	160 mm	80 mm	85 mm	Request
0402103900	MBT 168090K	160 mm	80 mm	90 mm	Request
0402104000	MBT 208055K	200 mm	80 mm	55 mm	Request
0402109700	MBT 208011K	200 mm	80 mm	110 mm	Request
0402107510	MBT 248055K	240 mm	80 mm	55 mm	Request
0402104200	MBT 121255K	122 mm	120 mm	55 mm	Request
0402104400	MBT 121275K	122 mm	120 mm	75 mm	Request
0402104600	MBT 121285K	122 mm	120 mm	85 mm	Request
0402104800	MBT 121211K	122 mm	120 mm	105 mm	Request
0402104900	MBT 161255K	160 mm	120 mm	55 mm	Request
0402105000	MBT 161270K	160 mm	120 mm	70 mm	Request
0402105100	MBT 161275K	160 mm	120 mm	75 mm	Request
0402105200	MBT 161290K	160 mm	120 mm	90 mm	Request
0402105300	MBT 161212K	160 mm	120 mm	120 mm	Request
0402105400	MBT 161214K	160 mm	120 mm	140 mm	Request
0402105600	MBT 201255K	200 mm	120 mm	55 mm	Request
0402105700	MBT 201270K	200 mm	120 mm	70 mm	Request
0402105900	MBT 201275K	200 mm	120 mm	75 mm	Request
0402106100	MBT 201290K	200 mm	120 mm	90 mm	Request
0402106900	MBT 241270K	240 mm	120 mm	70 mm	Request
0402106800	MBT 241210K	240 mm	120 mm	100 mm	Request
0402106200	MBT 201555K	200 mm	150 mm	55 mm	Request
0402106300	MBT 201575K	200 mm	150 mm	75 mm	Request
0402106400	MBT 201580K	200 mm	150 mm	80 mm	Request
0402106500	MBT 201510K	200 mm	150 mm	100 mm	Request
0402106600	MBT 201511K	200 mm	150 mm	105 mm	Request
0402106700	MBT 201513K	200 mm	150 mm	125 mm	Request
0402108200	MBT 341555K	340 mm	150 mm	55 mm	Request
0402108300	MBT 341580K	340 mm	150 mm	75 mm	Request
0402108500	MBT 341510K	340 mm	150 mm	100 mm	Request
0402108600	MBT 341512K	340 mm	150 mm	120 mm	Request
0402105500	MBT 161665K	160 mm	160 mm	65 mm	Request
0402107030	MBT 241670K	240 mm	160 mm	70 mm	Request
0402107000	MBT 241690K	240 mm	160 mm	90 mm	Request
0402107100	MBT 241612K	240 mm	160 mm	120 mm	Request
0402107200	MBT 251655K	250 mm	160 mm	55 mm	Request
0402107300	MBT 251685K	250 mm	160 mm	85 mm	Request
0402107400	MBT 251690K	250 mm	160 mm	90 mm	Request
0402107500	MBT 251611K	250 mm	160 mm	115 mm	Request
0402107600	MBT 251612K	250 mm	160 mm	120 mm	Request
0402107700	MBT 251615K	250 mm	160 mm	150 mm	Request
0402108700	MBT 362015K	360 mm	200 mm	150 mm	Request
0402107800	MBT 302365K	300 mm	230 mm	65 mm	Request
0402107900	MBT 302385K	300 mm	230 mm	85 mm	Request
0402108000	MBT 302311K	300 mm	230 mm	110 mm	Request
